TeckWrap’s Acid Lime (RB07-HD) Vinyl Wrap delivers an eye-catching, high-gloss finish, perfect for enhancing the look of your vehicle. Made from premium-grade polymeric multilayered calendared vinyl, this wrap ensures long-lasting durability and smooth, bubble-free application thanks to its air-release channels. Designed for superior stretchability, it conforms easily to every edge and curve of your vehicle. The solvent-based polyacrylate adhesive provides a safe, easy installation process and is gentle on your vehicle’s paint, ensuring hassle-free removal when needed.

Key Benefits:

• Durable & Conformable: Crafted from premium polymeric vinyl, the wrap conforms seamlessly to your vehicle’s curves and edges, ensuring smooth coverage.
• Vibrant High-Gloss Finish: The Acid Lime color provides a bold, glossy appearance that stands out.
• Air-Release Channels: Features air-release channels for an easy, bubble-free application, even for beginners.
• Safe Adhesive: The solvent-based polyacrylate adhesive ensures a secure yet paint-safe application and removal.

Product Specifications:

Property	Unit & Value	Test Method	Instruments
Thickness of the Film	122 μm	GB/T 2792-1998	Digital Thickness Gauge
Thickness of the Release Liner	142 μm	GB/T 2680	PE950 Spectrophotometer
Visible Light Transmission (VLT)	71%	ASTM D1003	PE950 Spectrophotometer
Visible Light Reflection	10%	ASTM D1003	PE950 Spectrophotometer
UV Block	99%	GB/T 2680	PE950 Spectrophotometer
Infrared Heat Rejection	90%	LS162	LS162
Total Solar Energy Rejected	45%	/	/
Adhesion Strength	≥70 N/25mm	GB/T 4851-1998	PE950 Spectrophotometer

Aging Resistance:

• High Temperature Aging: No adhesive residue after 7 days at 65°C.
• Low Temperature Aging: No adhesive residue after 10 days at -65°C.

Application Guidelines:

• Recommended Tools: Squeegee, buffer, knife, masking tape, heat gun, magnets, gloves, IR thermometer, IR heater.
• Application Method: Follow standard methods for calendered films. Avoid overstretching, and apply post-heating for optimal adhesion.
• Post-Heating Temperature: 100°C for best results.
• Cure Time: Allow 24 hours above 10°C for full adhesion.
• Storage Conditions: Store at +10°C to +20°C, with a relative humidity of 50%, in a clean, dry place away from direct sunlight for up to 2 years.

Important Notes:

• HD Products: Products with "HD" in their SKU include a plastic release liner, designed specifically for high-gloss films.
• Directional: Yes, this film is directional.
• Color Swatch: Always refer to the color swatch for an accurate representation. Slight color variations can occur between batches.
• Scratch Resistance: The film may scratch during installation or normal use. Scratching is not covered under warranty.
• Batch Consistency: To maintain color consistency across your vehicle, ensure that rolls from the same production lot number are used.

Warranty & Durability:

• Durability: The Acid Lime (RB07-HD) Vinyl Wrap is highly durable, with excellent resistance to the elements and UV rays.
• Warranty: Full warranty details are available in our Datasheet.
